Description
- Android™ 10.0
- 4G (LTE)
- Bluetooth® 5.0
- 5.5 in Dragontrail Glass
- Universal, lateral ISM interface
- PTT ready (third party application provided)
- Usable with gloves
- 2-year warranty
Technical Data
| Type | IS655.2 |
|---|---|
| Operating System | Android™ 10.0 |
| Size | 6 x 2.97 x .49 in (152.5 x 75.4 x 12.5 mm) |
| Weight | .45 lbs (203 g) |
| PTT ready | optional (third party application provided) |
| LWP ready | optional (third party application provided) |
| Bluetooth® | 5.0 |
| Frequencies | 2G GSM 850/900/1800/1900 MHz 3G WCDMA 850/1900/2100 MHz 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28 4G LTE-TDD: B38/B40/B41 |
| Wi-Fi® | 2.4 GHz + 5 GHz IEEE 802.11 b/g/n/ac with hotspot |
| NFC | Near Field Communication |
| Display | 5.5″ (13.97 cm) Dragontrail Glass, usable with gloves |
| Processor | Mediatek Helio P22 (MT6762V) Octa Core |
| Memory | 32 GB internal memory, 3 GB RAM |
| Micro-SD | up to 128 GB |
| Camera | 13 MP AF rear, 8 MP FF front |
| Battery | 4200 mAh, 3.8 V |
| Operation range from | -10° C to 60° C |
| Security updates | Fully compliant with the requirements for Android Enterprise Recommended Rugged Devices. Quarterly security updates at least for five years from the launch. |
| Major upgrade | At least one major upgrade to Android 10 or higher. |
Resources
- Datasheet
- Safety Instructions and Quick Start
- CSA Certificate of Compliance
- EU Declaration of Conformity
- ATEX Certificate of Conformity
- IECEx Certificate of Conformity
K-COMM Push to Talk Solutions offers a push to talk solution that is tested and approved to run on the IS530.1 and IS530.2 Smartphones. Monthly subscription sold separately.
Approvals
- ATEX zone 2/22
II 3G Ex ic IIC T4 Gc IP54
II 3D Ex ic IIIB T135°C DC IP54 - IECEx zone 2/22
Ex ic IIC T4 Gc IP54
Ex ic IIIB T135°C Dc IP54 - CSA
(approved for North America)
Class I Div. 2 Groups A, B, C, D, T4
Class II Div. 2 Groups F, G, T135°C
Class III Div. 2 - KCs
(approved for South Korea)
Ex ic IIC T4
Ex ic IIIB T135°C
Included
- Smartphone with integrated battery
- Adapter universal
- Micro USB Cable
- Display Protection Foil
- Safety Instructions
- Quick Start Manual
